Helios
This is Soundsmith's new medium output design. All other technical specifications are identical to the HYPERION.
TECHNICAL SPECIFICATIONS
Stylus: Contact Line Nude, 0.100mm SQ
Radius of curvature: Selected CL or Optimized (OCL)
Cantilever: Hand formed selected Cactus Needle
Recommended Tracking force: 1.8 to 2.2 Grams
Effective tip mass: 0.30 mg
Compliance: 10 µm/mN (low compliance)
Frequency response: 20-20,000 Hz ± 1.0 dB
Channel Separation (stereo only)
1000 Hz >36 dB
50-15,000 >25 dB
Channel difference:
<0.5 dB (Stereo)
<1.0 dB (Mono)
Output voltage: 5 cm/sec. Lat. RMS 0.3 mV
Cartridge weight: 10.25 Grams
Loading HYPERION: >= 470 Ω
Loading HELIOS: >= 1.5 kΩ
